Consisting of the M4R belt-pack diversity receiver and the M4T half-rack transmitter, the Quadra system features digital RF modulation, two or four channels of 24-bit/48kHz digital audio, analogue or digital inputs, and a unique mixing interface for users. The system operates in the license-free ISM (902MHz -928MHz) band and has a throughput latency of 1ms for the analog inputs and <0.5ms for the digital inputs.
The M4R diversity belt-pack receiver features a user-friendly interface with a high-resolution, backlit LCD and membrane switches. A four-channel mixer enables the performer to tailor the mix in real time, based on what is sent to the transmitter from the monitor console. Several channel set-ups and knob configurations are available, providing a variety options for system operation. The M4R runs for six hours on three alkaline AA batteries.
The M4T half-rack transmitter features transmission power of 200mW for extended operating range. Locking XLR connectors facilitates up to four channels of either analogue or digital (AES/EBU) audio sources to be applied to the transmitter. A large, high-resolution, backlit LCD and large membrane switches provide an intuitive interface. The included hardware supports rack-mounting of two M4T units together in a 1U configuration. A USB jack provides for future firmware updates in the field. The M4T operates on AC mains power, avoiding the use of a wall-wart.
‘We have been asked repeatedly for many years to make an IEM system,’ says Karl Winkler, Director of Business Development. ‘We didn’t want to make a “me-too” product, though. Instead, we based the Quadra system on our own D4 digital wireless platform, which has already been proven for film and TV production. I’m confident we have a unique solution for the touring market. Furthermore, by virtue of its use of the license-free ISM band, the Quadra can be added to most existing wireless microphone installations without ‘stepping on’ what is already in place.’
The system will be available in February 2011.
