L-Acoustics’ L-ISA immersive sound technology had made its North American musical theatre debut through Joe Iconis’ comedy Broadway Bounty Hunter, staged at Manhattan’s Greenwich House Theater.

After selling out its world premiere at Barrington Stage Company, the show moved to New York City for a month-long Off-Broadway run. It’s relocation to the Greenwich Village venue brought the need for a new loudspeaker design and created an opportunity for Sound Designer Cody Spencer to create a panoramic soundscape with L-ISA.

’Associate Sound Designer Stephen Jensen and I were very happy to have the opportunity to use L-ISA on Broadway Bounty Hunter,’ he says. ‘The localisation of the vocals and the fidelity we got from the band when we were able to space different instruments across the panorama of the stage was amazing. It led to crystal clear vocals, a lush and full-sounding band, and the ability to rock out but also pull back and keep the fidelity of the band when needed. The integration was super easy and Jesse Stevens and L-Acoustics provided unending support to make this a very smooth process. L-ISA is a game-changer for the musical theatre world.’

With show production handled by Sound Associates and L-ISA tools and support provided by See Factor, Spencer used five L-Acoustics X12 loudspeakers and two SB15m subwoofers as the base of the 13.1, 360° immersive set-up. Nine 5XT loudspeakers were placed around the audience for immersion, while another pair of 5XT served as near proscenium fills, and a series of four X8 served as fill for the venue’s small balcony. To fit snugly into the modest power draw allocated to the audio system, seven LA4X amplified controllers powered all of the loudspeakers in the space.

A total of 64 inputs representing nine actors, five musicians playing nine instruments, reverb engines, and a host of sound effects entered the show’s Yamaha CL3 FOH console, feeding out to the L-ISA Controller that served as the hub for object-based mixing of the 1970s funk-inspired score and sonic backdrop.

‘The CL3 generated a Madi signal via a Yamaha RMio64-D, which fed to a RME Madi router, acting as both a Madi stream switcher and combiner for the L-ISA Controller,’ Spencer explains. ‘The direct outs from the CL3 fed this Madi stream, which was split to the main and backup L-ISA Processors. Their individual speaker returns were returned via Madi to the Madi router, which then sent the final Madi signal to the amps. On the conversion side, an RME M-32 converted the Madi stream to analogue outputs to feed the L-Acoustics LA4X amplified controllers.’

All show control for the production was handled through QLab 3. CL3 and L-ISA cues, sound effects, and even integration of triggers to and from the lighting department were all managed on multiple cue lists in QLab. ‘And all moves within the L-ISA soundscape were stored in snapshots on the L-ISA Controller and recalled via OSC commands from QLab.’

‘L-ISA technology really brought a unique sound experience to our show,’ enthuses Broadway Bounty Hunter Production Manager, Erica Blumrosen. ‘Because it gives you a true surround sound experience, Cody was able to create sound that moved with the visuals of our projections and with our actors. Our play used the entire space on the stage, with the actors coming in and out of the audience constantly, and L-Acoustics really gave us the ability to match what the audience heard to what they saw in a way that a conventional theater rig would not have. It was a truly incredible auditory experience that made you feel like you were in the action and encouraged you to dance in your seat to Joe Iconis’ incredible music.’

Director and Choreographer Jennifer Werner shares Blumrosen’s enthusiasm: ‘Joe’s score is the heart and soul of Broadway Bounty Hunter, and the L-ISA audio design brought that score with our six-piece band fully alive – the music sounded so exciting!’ she says. ‘We were able to achieve that perfect balance of hearing every nuance in the orchestrations in concert with the actors’ soaring vocals.’

‘L-Acoustics was able to meet the gamut of audio design needs with a very tricky venue space,’ Werner adds. ‘I was able to have moments where the richness of the R&B/Funk score could really rock out, as well as have more intimately crafted moments of sound in the book scenes. The flexibility of L-ISA technology also gave me the tools to support any storytelling idea, which gave me the ability to create a fully environmental production where the audience was truly immersed in the sound.’

More: www.l-acoustics.com
