4HM SAM64 SDI-to-AES/Madi interface

The 4HM SAM64 is a cost-effective interface for connecting audio equipment to the SDI-based infrastructure used in many broadcast facilities. The 1U-high unit provides the interface between SDI video bitstreams and digital audio.

4HM SAM64SAM64 extracts 16 audio channels from each of its four SDI inputs to provide a total of 64 audio channels in both Madi (AES10id-2008) and AES3 (AES3-1992) formats. All SDI inputs independently auto-sense between 3G, HD and SD standards and are provided with loop-through connectivity for downstream equipment.

With a wide range of synchronising options and switchable sample rate convertors, the SAM64 is designed ‘to reliably and seamlessly’ integrate into any broadcast environment where SDI-embedded audio channels require format conversion. This invilved the provision of redundant power supplies, high-quality components and extensive test and QC procedures.

An optional 1U-high, 19-inch rack-mounting AES Signal Breakout panel (ASBO), enables the AES3-id outputs to be available on 32 BNC connectors (75 Ω).

More: www.4hmbroadcast.com
